G21 G94 G40
G91
G28 X0. Y0. Z0.
G90
M06 T1
M03 S1500
G00 X30. Y30. Z5.
G99
G83 X30. Y30. Z-25. Q0.5 F50.X70. Y50.
X30. Y70.
G80
M05
G91
G28 X0. Y0. Z0.
G90
M06 T2
M03 S1200
G00 X30. Y30. Z5.
G99
G74 X30. Y30. Z-25. Q0.5 R0.5 F2.
X30. Y70.
G80
M05G91
G28 X0. Y0. Z0.
G90
M06 T3
M03 S1500
G00 X70. Y50. Z5.
G99
G83 X70. Y50. Z-8. Q0.5 F50.
G80
M05
G91
G28 X0. Y0. Z0.
G90
M30
Drill-Tap-Countersink CNC programDrill-Tap-Countersink CNC programDrill-Tap-Countersink CNC programvery good knowledge gained thank you so much Fabrication Drawings preparation in USA
